| Rated Output |
tph |
100 |
160 |
200 |
250 |
| Four Bin Feeder |
|
|
|
|
|
| No. of Bins */ Total Capacity |
nos/m³ |
4/22 |
4/22 |
4/25 |
4/32 |
| Charging Width |
mts |
2.75 |
2.75 |
3 |
3.6 |
| Auxilary Drive Motor |
kw |
4x1.5 |
4x1.5 |
4x1.5 |
4x2.2 |
| Gathering Conveyor Belt (wxL) |
mm |
600x25600 |
600x23500 |
600x29600 |
600x36880 |
| Gathering Drive Motor |
kw |
3.7 |
3.7 |
3.7 |
5.5 |
| Bin Vibrator (1 no.) |
kw |
0.37 |
0.37 |
0.37 |
0.37 |
| Fedding Capicity |
tph |
120 |
180 |
225 |
260 |
| Over Size Removal Screen |
|
|
|
|
|
| Mesh Size |
mm |
65x65 |
65x65 |
65x65 |
65x65 |
| Drive Motor |
kw |
0.75 |
0.75 |
0.75 |
0.75 |
| Charging Conveyor |
|
|
|
|
|
| Conveyor Belt (WXL) |
mm |
600x14400 |
600x14400 |
600x15025 |
600x15025 |
| Conveyor Drive Motor |
kw |
3.7 |
3.7 |
3.7 |
5.5 |
| Pug Mill |
|
|
|
|
|
| No of Paddle Arms |
|
26 |
32 |
44 |
64 |
| Drive Motor |
kw |
18.5 |
30 |
37 |
45 |
| Capacity |
m³ |
1.62 |
1.9 |
2.4 |
3 |
| Water Tank(Optional) |
|
|
|
|
|
| Capacity |
m³ |
10 |
15 |
18 |
18 |
| Drive Motor |
kw |
1.5 |
3.7 |
3.7 |
5.5 |
| Load out converyor with Gob Hopper |
|
|
|
|
|
| Belt (WXL) |
mm |
600x17900 |
600x17900 |
600x20300 |
- |
| Drive Motor |
kw |
3.7 |
3.7 |
5.5 |
- |
| Gob Hopper Capacity |
mt |
1 |
1 |
1.5 |
- |
| Hydraulic Power Pack |
kw |
1.5 |
1.5 |
2.2 |
- |
| Load out converyor with Storage Silo (Optional with WMM-100,160,200,250) |
|
|
|
|
|
| Belt (WXL) |
mm |
600x41100 |
800x41100 |
800x41100 |
800x41100 |
| Drive Motor |
kw |
7.5 |
11 |
11 |
11 |
| Storage Silo Capacity* |
mt |
25 |
25 |
25 |
25 |
| Hydraulic Power Pack |
kw |
3.7 |
3.7 |
3.7 |
3.7 |
| Total connected Load |
kw |
45.6 |
73.3 |
80.8 |
88.3 |
| Recommended Genset Capacity |
kva |
62 |
82.5 |
100 |
125 |
| Open Land Requriment |
mts |
50x35 |
55x35 |
55x35 |
55x35 |
| Filler Silo (Optional) |
|
|
|
|
|
| Capacity |
m³ |
- |
28.5 |
28.5 |
25.5 |
