Rated Output@3% moistue Content |
tph |
40-60 |
60-90 |
90-120 |
120-150 |
| Units |
|
|
|
|
|
|
| Feeder |
No of Bins*/ total capicity |
nos/m³ |
4/20 |
4/22 |
4/25 |
4/32 |
|
Charging Width |
mtrs |
2.5 |
2.75 |
3 |
3.6 |
|
Auxillary Conveyor Drive Motor |
kw |
4x1.5 |
4x1.5 |
4x1.5 |
4x2.2 |
|
Gathering Conveyor Belt (wxL) |
mm |
600x22500 |
600x23500 |
600x29600 |
600x29600 |
|
Gathering Conveyor Drive Motor |
kw |
3.7 |
3.7 |
3.7 |
5.5 |
|
Bin Vibrator (1 no.) |
kw |
0.37 |
0.37 |
0.37 |
0.37 |
|
Fedding Capicity |
tph |
80 |
110 |
140 |
180 |
| Over Size Removal Screen |
Wire Mesh Size |
mm |
45x45 |
45x45 |
45x45 |
45x45 |
|
Drive Motor |
kw |
0.75 |
0.75 |
0.75 |
0.75 |
| Slinger Conveyor |
Conveyor Belt (WXL) |
mm |
600x14400 |
600x14400 |
600x15025 |
600x20400 |
|
Conveyor Drive Motor |
kw |
3.7 |
3.7 |
3.7 |
5.5 |
| Thermo Drum |
Dryer (LXD) |
mts |
6.0x1.2 |
6.7x1.5 |
7.3x1.8 |
7.9x1.8 |
|
Drive Type* |
Drive |
Chain/Cradle Type |
Chain/Cradle Type |
Chain/Cradle Type |
Cradle Type |
|
Drive Motor |
kw |
15 |
18.5 |
30 |
4x7.5 |
|
Burner Capicty |
lph/MW |
250/3 |
350/5.5 |
550/9.5 |
770/14 |
|
Fuel* |
|
LDO |
LDO |
LDO |
LDO |
|
Blower Connected Load |
kw |
5.5 |
7.5 |
11 |
15 |
|
Exauster |
cfm/kw |
10500/15 |
14500/18.5 |
16500/30 |
with CV unit |
| Dust Control unit (Primary) |
|
|
|
|
|
|
| Primary Multicone |
Nos of Cone. |
|
15 |
20 |
21 |
21 |
| Dry Dust Colltector |
Dust Screw Drive |
kw |
0.75 |
0.75 |
1.5 |
1.5 |
| Load Out Conveyor |
Belt (WXL) |
mm |
600x17900 |
600x17900 |
600x20300 |
600x20300 |
|
Drive Motor |
kw |
3.7 |
3.7 |
5.5 |
5.5 |
| Gob Hopper |
Gob Hopper Capicty |
mt |
1500 |
1500 |
2000 |
2000 |
|
Hyadrulic Power Pack |
kw |
1.5 |
1.5 |
2.2 |
3.7 |
| Mineral Filer Unit |
Capcity |
m-³ |
1.5 |
1.5 |
1.5 |
1.5 |
|
Drive Motor |
kw |
0.75 |
0.75 |
0.75 |
0.75 |
|
Air Compressor Connected Load |
kw |
1.5 |
1.5 |
2.2 |
2.2 |
| Bitumen Tank |
Capcity |
Ton |
15 |
20 |
25 |
30 |
|
Heating System* |
|
Direct Heating |
Direct Heating |
Direct Heating |
Direct Heating |
|
Bitumen Pump Model |
|
2"x2" |
2"x2" |
2"x2" |
RDRB-250 |
|
Bitumen Motor |
kw |
3.7 |
3.7 |
3.7 |
5.5 |
| (Optional) |
Hot oil Pump |
|
3/4"x3/4" |
3/4"x3/4" |
3/4"x3/4" |
- |
| (Optional) |
Hot oil Motor |
kw |
0.75 |
0.75 |
0.75 |
- |
| Fuel Tank |
Capcity |
Liter |
4000 |
4000 |
8000 |
12,000 |
|
Fuel Feeding Pump (LXO) |
mm |
19.05/19.05 |
19.05/19.05 |
19.05/19.05 |
19.05/19.05 |
|
Fuel Motor |
kw |
0.75 |
0.75 |
0.75 |
0.75 |
| FO Kit (Optional) |
Outflow Heater |
kw |
4.5 |
4.5 |
4.5 |
9 |
|
In - line Heater |
kw |
14.5 |
18.5 |
18.5 |
18.5 |
| Total connected Load |
|
kw |
73.7 |
89.8 |
126.2 |
135.2 |
| Recommended Genset Capacity |
|
KVA |
82.5 |
100 |
125 |
150 |
| Open Land Requrinent |
|
mts |
35x30 |
35x35 |
40x40 |
|
| Pollution Control Unit - Secondary Dust Collector (Optional): |
|
|
|
|
|
| Wet Dust Collector |
Type |
|
Ventury Type |
Ventury Type |
Ventury Type |
|
| CV series |
Water Pump |
kw |
1.5 |
1.5 |
2.2 |
|
| Bag House Filter |
Type |
|
|
|
|
|
|
Dust Emission |
mg/Nm-³ |
|
|
|
|
|
Filter Area |
m-² |
|
|
|
|
|
Exhauster |
cfm/kw |
|
|
|
|
